Запчасти Komatsu PC270LC-6LE FIG NO. H- ОСНОВН. КЛАПАН КОРПУС ГИДРАВЛИКА

1

20Y-62-A1340

BRACKET, MAIN CONTROL VALVE

2

01010-81655

BOLT

3

01643-31645

WASHER

4

01010-81650

BOLT

5

01643-31645

WASHER

6

20Y-62-27191

BRACKET - S/N A83001-A85000

6

20Y-62-27192

BRACKET - S/N A85001 AND UP

7

01010-81230

BOLT

8

01643-31232

WASHER

9

20Y-62-21263

BRACKET - S/N A83001-A85000

9

20Y-62-21264

BRACKET - S/N A85001 AND UP

10

01010-81235

BOLT

11

01643-31232

WASHER

12

702-21-09147

VALVE ASSEMBLY

13

21T-09-11460

O-RING

14

708-27-12560

BOLT

15

01643-51032

WASHER

16

07371-31049

FLANGE

17

07372-21035

BOLT

18

01643-51032

WASHER

19

21Y-62-17810

ELBOW ASSEMBLY

20

07002-12434

O-RING

21

07235-10210

ELBOW

22

07002-11423

O-RING

23

07235-10210

ELBOW

24

07002-11423

O-RING

25

07371-31049

FLANGE

26

07372-21035

BOLT

27

01643-51032

WASHER

|$29

20Y-62-27241

HOSE ASSEMBLY

28

203-62-52280

HOSE

29

20Y-62-22881

HOSE

30

20Y-62-22820

BAND - BLUE

31

07096-00221

HOSE

32

20Y-62-22810

BAND, YELLOW

33

04434-52712

CLIP

34

01010-81225

BOLT

35

01643-31232

WASHER

36

08034-00519

BAND, WHITE

37

04434-51512

CLIP
