Запчасти Komatsu PC270LC-6LE FIG NO. H-C7A ОСНОВН. КЛАПАН PRESSURE COMPENSATION КЛАПАНS ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
|$4
NSS
SUB-ASSEMBLY, BODY
1
723-46-41110
VALVE
2
723-46-41120
VALVE
|$7
723-46-40100
VALVE ASSEMBLY, PRESSURE COMPENSATION
3
NSS
SLEEVE
4
NSS
SUB-ASSEMBLY, PISTON
5
NSS
SPRING
6
NSS
SEAL
7
700-93-11320
O-RING
8
723-46-41950
RING
9
07002-13634
0-RING
|$15
723-46-40702
VALVE ASSEMBLY, PRESSURE COMPENSATION
10
NSS
SLEEVE
11
NSS
PISTON
12
NSS
SPRING
13
NSS
SEAL
14
NSS
SEAL
15
700-93-11320
O-RING
16
723-46-41950
RING
17
07002-13634
O-RING
18
723-46-42981
PLUG
19
07002-12434
O-RING
|$26
723-46-41100
VALVE ASSEMBLY, PRESSURE COMPENSATION
20
NSS
SLEEVE
21
NSS
PISTON SUB-ASSEMBLY
22
NSS
SPRING
23
NSS
SEAL
24
700-93-11320
O-RING
25
723-46-41950
RING
26
07002-13634
O-RING
|$34
723-46-45100
VALVE ASSEMBLY, PRESSURE COMPENSATION
27
NSS
SLEEVE
28
NSS
PISTON SUB-ASSEMBLY
29
NSS
SPRING
30
NSS
SEAL
31
700-93-11320
O-RING
32
723-46-41950
RING
33
07002-13634
O-RING
|$42
723-46-46101
VALVE ASSEMBLY, PRESSURE COMPENSATION
34
NSS
SLEEVE
35
NSS
PISTON SUB-ASSEMBLY
36
NSS
SPRING
37
NSS
SEAL
38
700-93-11320
O-RING
39
723-46-41950
RING
40
07002-13634
O-RING
|$50
723-46-43200
VALVE ASSEMBLY, PRESSURE COMPENSATION
41
NSS
SLEEVE
42
NSS
VALVE SUB-ASSEMBLY
43
NSS
SPRING
44
NSS
SEAL
45
700-93-11320
O-RING
46
723-46-41950
RING
47
07002-13634
O-RING
48
723-46-41980
RETAINER
|$59
723-46-46300
VALVE ASSEMBLY, PRESSURE COMPENSATION
49
NSS
SLEEVE
50
NSS
PISTON SUB-ASSEMBLY
51
NSS
SPRING
52
NSS
SEAL
53
700-93-11320
O-RING
54
723-46-41950
RING
55
07002-13634
O-RING
Выбрано товаров: 63
