Запчасти Komatsu PC270-8 ПОРШЕНЬ НАСОС (ВНУТР. ЧАСТИ, ОСНОВН. НАСОС) (8/) B [КОМПОНЕНТЫ ДВИГАТЕЛЯ]

|$1

708-2L-00390

PUMP ASSEMBLY, PISTON

|$2

708-2L-01390

PUMP SUBASSEMBLY

1

708-2L-34180

SLIDER

|$4

708-2L-06682

VALVE ASSEMBLY

|$5

708-2L-06660

PISTON ASSEMBLY, SERVO

2

PISTON, SERVO

3

PLUG

4

708-2L-35680

SEAL

5

708-2L-35260

PLUG

6

708-2L-35760

BALL

7

708-2L-35770

PLUG

8

708-2L-35690

SEAL

9

708-2L-35281

PIN

10

708-2L-35860

SPOOL

11

708-2L-35630

RETAINER

12

708-2L-35641

SEAT

13

708-2L-35240

SPRING

14

708-2L-35730

SPRING

15

708-2L-35650

SEAT

16

708-2L-35250

SPRING

17

708-2L-34330

SCREW

18

07000-B3034

O-RING

19

708-2L-35210

RING, BACK-UP

20

708-2L-35710

SEAL

21

708-2L-35270

PLUG

22

07000-B2011

O-RING

23

07000-B3045

O-RING

24

708-2L-35750

RING, BACK-UP

25

708-2L-34310

COVER

26

01580-10806

NUT

27

708-2L-35290

NUT

28

708-2L-35670

RING, WIRE

29

01252-61440

BOLT, HEXAGON SOCKET HEAD
