Запчасти Komatsu PC270-8 ГИДР. БАК., ЭЛЕМЕНТ И ФИЛЬТР (№7-) ГИДР. БАК., С СТРЕЛА И РУКОЯТЬ ANTI-DROP КЛАПАН

1

207-60-71182

Element, Hydraulic Oil Filter

2

20Y-60-31140

Strainer

3

20Y-60-31131

Valve Assembly

4

20Y-60-21240

Spring

5

22U-60-21232

Cover

6

07000-15195

O-ring

7

01010-81230

Bolt

8

01643-31232

Washer

|$8

20Y-60-31171

Strainer Assembly

9

207-60-61150

Rod Assembly

10

20Y-60-21320

Holder

11

12R-60-11230

Spring

12

22B-60-11160

Strainer

13

20Y-60-41212

Cover

14

07000-15160

O-ring

15

01010-81230

Bolt

16

01643-31232

Washer

17

17A-60-11310

Cap Assembly

18

20Y-60-21470

Element

19

208-60-71180

Filler Neck

20

20Y-60-21340

Gasket

21

01252-70516

Bolt

22

01601-20513

Washer

23

07285-00155

Clip

24

206-60-41240

Tube

|$25

20Y-60-31271

Breather Assembly

25

207-60-51311

Element

26

207-60-51320

Seal

27

Body

28

Cover

29

Nut

30

Nut

31

Packing

32

01252-70516

Bolt

33

01601-20513

Washer

34

205-00-73360

Plate, Operating

35

01010-81635

Bolt

36

01643-31645

Washer
