Запчасти Komatsu PC270-8 АНТИКОРРОЗ. ЭЛЕМЕНТ (№7-7) АНТИКОРРОЗ. ЭЛЕМЕНТ, С КОНДИЦИОНЕРОМ, ДЛЯ HARD ВОДН. AREA ARRANGEMENT

1

6738-61-8100

Corrosion Resistor Assembly

2

01010-81030

Bolt

3

01643-31032

Washer

4

205-04-62150

Joint

5

07206-31014

Bolt, Joint

6

07005-01412

Seal, Washer

7

20Y-62-51590

Elbow

8

07002-11823

O-ring

9

20Y-01-41280

Bracket

10

01010-81225

Bolt

11

01643-31232

Washer

12

20Y-01-41320

Hose Assembly

13

04434-51612

Clip

14

01010-81225

Bolt

15

01643-31232

Washer

16

08034-20536

Band

17

04434-51912

Clip

18

01010-81265

Bolt

19

01643-31232

Washer

20

20Y-03-11220

Collar

21

04434-51612

Clip

22

11Y-09-11140

Clip

23

09483-10311

Hose

24

04434-51612

Clip

25

01010-81265

Bolt

26

01643-31232

Washer

27

20Y-03-11220

Collar

28

04435-51612

Clip

29

01010-81225

Bolt

30

01643-31232

Washer

31

11Y-09-11140

Clip

32

20Y-01-41310

Block

33

01010-81265

Bolt

34

01643-31232

Washer

35

20Y-03-11220

Collar

36

205-04-62150

Joint

37

07206-31014

Bolt, Joint

38

07005-01412

Seal, Washer

39

07043-70312

Plug

40

11Y-09-11160

Clip

41

20Y-01-41330

Hose Assembly

42

04434-52112

Clip

43

01010-81225

Bolt

44

01643-31232

Washer
