Запчасти Komatsu PC270-8 АНТИКОРРОЗ. ЭЛЕМЕНТ (№7-7) АНТИКОРРОЗ. ЭЛЕМЕНТ, ДЛЯ HARD ВОДН. AREA ARRANGEMENT

1

6738-61-8100

Corrosion Resistor Assembly

2

01010-81030

Bolt

3

01643-31032

Washer

4

205-04-62150

Joint

5

07206-31014

Bolt, Joint

6

07005-01412

Seal, Washer

7

20Y-62-51590

Elbow

8

07002-11823

O-ring

9

20Y-01-41280

Bracket

10

01010-81225

Bolt

11

01643-31232

Washer

12

20Y-01-41320

Hose Assembly

13

04434-51612

Clip

14

01010-81225

Bolt

15

01643-31232

Washer

16

08034-20536

Band

17

04434-51912

Clip

18

01010-81265

Bolt

19

01643-31232

Washer

20

04434-51612

Clip

21

11Y-09-11140

Clip

22

09483-10311

Hose

23

04434-51612

Clip

24

01010-81265

Bolt

25

01643-31232

Washer

26

20Y-03-11220

Collar

27

04435-51612

Clip

28

01010-81225

Bolt

29

01643-31232

Washer

30

11Y-09-11140

Clip

31

20Y-01-41310

Block

32

01010-81265

Bolt

33

01643-31232

Washer

34

205-04-62150

Joint

35

07206-31014

Bolt, Joint

36

07005-01412

Seal, Washer

37

20T-54-42510

Nipple

38

11Y-09-11160

Clip
