Запчасти Komatsu PC270-8 ЦИЛИНДР РУКОЯТИ(СИСТЕМА СМАЗКИ 100 ЧАС.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XP400

ARM CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0K400

CYLINDER ASS'Y

1

707-13-15280

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

707-58-11740

ROD,PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-15650

HEAD,CYLINDER

8

07179-13126

RING,SNAP

9

707-56-11740

SEAL,DUST

10

707-52-90850

BUSHING

11

707-75-11040

RING

12

707-51-11030

PACKING,ROD (KIT)

13

07000-15140

O-RING (KIT)

14

707-35-91660

RING,BACK-UP (KIT)

15

707-51-11650

RING,BUFFER (KIT)

16

01010-82085

BOLT

17

707-88-75310

WASHER

18

707-36-15260

PISTON

19

707-44-15150

RING,PISTON (KIT)

20

707-39-15110

RING,WEAR (KIT)

21

707-44-15911

RING

22

707-71-61140

PLUNGER

23

07000-15100

O-RING (KIT)

24

07001-05100

RING,BACK-UP (KIT)

25

01310-01216

SCREW

26

707-71-80280

PLUNGER

27

07020-00000

FITTING,GREASE

28

707-71-35030

COLLAR

29

707-35-91660

RING,BACK-UP (KIT)

30

07000-15140

O-RING (KIT)

31

04260-00635

BALL

32

707-71-91270

CAP

33

707-83-13010

VALVE

34

07750-01628

SPRING

35

707-87-14070

PLUG

36

07002-12034

O-RING (KIT)

37

707-86-67920

TUBE

38

20D-62-17860

ELBOW

39

07372-51060

BOLT

40

01643-51032

WASHER

41

07372-51045

BOLT

42

01643-51032

WASHER

43

07000-13030

O-RING (KIT)

44

01010-81080

BOLT

45

01643-31032

WASHER

46

07000-13035

O-RING (KIT)

47

707-88-22670

BRACKET

48

707-88-21351

BAND

49

07372-21035

BOLT

50

01643-51032

WASHER

51

707-88-36130

PLATE

52

07283-32738

CLIP

53

01597-01009

NUT

54

01643-31032

WASHER

55

707-88-33030

CAP,(FOR SHIPPING)

56

07371-30640

FLANGE,SPLIT

57

707-88-33040

CAP,(FOR SHIPPING)

58

07371-31049

FLANGE,SPLIT

59

07372-21035

BOLT,(FOR SHIPPING)

60

01643-51032

WASHER,(FOR SHIPPING)

|$66

707-99-59740

SERVICE KIT
