Запчасти Komatsu PC270-7 БЛОК В СБОРЕ (ОХЛАЖД-Е) (С КОНДИЦИОНЕРОМ)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
№
Артикул
Название
Примечание
Количество
|$1
ND448800-5222
UNIT ASS'Y,COOLING
1
ND245450-2221
CASE,COOLING
2
ND245450-1721
CASE,COOLING
3
ND116569-5010
PLATE
4
ND447600-4970
EVAPORATOR
5
ND949142-0030
O-RING
6
ND116120-7990
CORE ASS'Y,HEATER
7
ND447500-1390
VALVE,EXPANSION
8
ND949046-2150
BOLT
9
ND446870-5650
TUBE,ACCESSORY
10
ND949142-0030
O-RING
11
ND949142-0010
O-RING
12
ND077500-0710
THERMISTOR
13
ND246690-2840
CLAMP
14
ND116650-8800
DOOR ASS'Y
15
ND116650-8820
DOOR ASS'Y
16
ND116650-8840
DOOR ASS'Y
17
ND116640-4652
DAMPER ASS'Y
18
ND443440-0030
SWITCH,PRESSURE
19
ND949142-0040
O-RING
20
ND446830-3880
TUBE
21
ND446810-9520
TUBE,SUCTION
22
ND949142-0030
O-RING
23
ND146678-4930
PACKING
24
ND949321-9940
GROMMET
25
ND246770-6990
CLAMP,PIPING
26
ND017231-1400
CLAMP
27
ND017660-3490
BRACKET
28
ND170400-4310
SENSOR ASS'Y,THERMO
29
ND146690-6020
CLAMP
30
ND246634-6010
BRACKET
31
ND499300-2051
I.C. POWER
32
ND063700-7200
SERVO MOTOR ASS'Y
33
ND063700-7210
SERVO MOTOR ASS'Y
34
ND116569-5020
PLATE
35
ND116682-0930
LEVER
36
ND116682-0960
LEVER
37
ND116662-4850
SHAFT
38
ND116569-5030
PLATE
39
ND116682-0940
LEVER
40
ND116682-0951
LEVER
41
ND116569-5041
PLATE
42
ND116569-5051
PLATE
43
ND116662-4860
SHAFT
44
ND116569-5062
PLATE
45
ND116682-0920
LEVER
46
ND116682-0910
LEVER
47
ND949008-0460
SCREW,TAPPING
48
17M-911-3290
CLAMP
49
ND146535-1311
BRACKET
50
ND146535-0411
BRACKET
51
ND146525-6070
BRACKET
52
ND91310-03081
SCREW,WASHER
53
ND949001-1730
SCREW,TAPPING
54
ND90930-05121
SCREW,TAPPING
55
ND90930-06141
SCREW,TAPPING
56
ND146535-0421
BRACKET
57
ND90930-05161
SCREW,TAPPING
58
ND116682-3440
LEVER
59
ND017730-8380
LEVER,CONTROL
60
ND116660-2770
DOOR ASS'Y
61
ND146698-6930
PACKING
62
ND146698-6950
PACKING
63
ND146698-8480
PACKING
64
ND146637-5650
PACKING
65
ND146647-0712
PACKING
66
ND146647-3880
PACKING
Выбрано товаров: 67
