Запчасти Komatsu PC270-7 ЦИЛИНДР КОВША ( ЧАС. СИСТЕМА СМАЗКИ) (A ТИП)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XZ952

CYLINDER GROUP,(FINAL COATING)

G-1

707-01-XZ952

CYLINDER GROUP,(FINAL COATING)

|$5

707-01-0A422

CYLINDER ASS'Y

1

707-13-14571

CYLINDER

2

707-58-10710

ROD,PISTON

3

707-76-80431

BUSHING

4

07145-00080

SEAL,DUST (KIT)

5

07020-00900

FITTING,GREASE

6

707-76-80480

BUSHING

7

20Y-70-23230

SEAL,DUST (KIT)

8

07020-00000

FITTING,GREASE

9

707-27-14690

HEAD,CYLINDER

10

176-63-56170

SEAL,DUST (KIT)

11

07179-13114

RING,SNAP

12

707-51-10030

PACKING,ROD (KIT)

13

707-51-10640

RING,BUFFER (KIT)

14

707-52-90781

BUSHING

15

07000-15130

O-RING (KIT)

16

707-35-91420

RING,BACK-UP (KIT)

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

707-75-10160

RING,SNAP

20

707-36-14650

PISTON

21

707-44-14180

RING,PISTON (KIT)

22

707-39-14110

RING,WEAR (KIT)

23

707-44-14910

RING

24

07000-15090

O-RING (KIT)

25

07001-05090

RING,BACK-UP (KIT)

26

01310-01216

SCREW

27

707-86-66391

TUBE

28

07372-21060

BOLT

29

01643-51032

WASHER

30

07372-21045

BOLT

31

01643-51032

WASHER

32

07000-13030

O-RING (KIT)

33

707-88-22680

BRACKET

34

707-88-21361

BAND

35

07372-21035

BOLT

36

01643-51032

WASHER

37

01643-31032

WASHER

38

01597-01009

NUT

39

07283-32738

CLIP

40

01643-51032

WASHER

41

07372-21035

BOLT

42

707-88-33030

CAP

43

07371-30640

FLANGE,SPLIT

|$50

707-99-58060

SERVICE KIT
