Запчасти Komatsu PC270-7 ЦИЛИНДР РУКОЯТИ(СИСТЕМА СМАЗКИ 100 ЧАС.) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XS210

CYLINDER GROUP,(FINAL COATING)

|$3

707-01-0H420

CYLINDER ASS'Y

1

707-13-15240

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL,DUST (KIT)

4

707-58-11351

ROD,PISTON

5

707-76-80010

BUSHING

6

07145-00080

SEAL,DUST (KIT)

7

707-27-15610

HEAD,CYLINDER

8

07179-13126

RING,SNAP

9

198-63-94170

SEAL,DUST (KIT)

10

707-52-90850

BUSHING

11

707-51-11030

PACKING,ROD (KIT)

12

07000-15140

O-RING (KIT)

13

707-35-91660

RING,BACK-UP (KIT)

14

707-51-11640

RING,BUFFER (KIT)

15

01010-82085

BOLT

16

707-88-75310

WASHER

17

707-36-15260

PISTON

18

707-44-15180

RING,PISTON (KIT)

19

707-39-15110

RING,WEAR (KIT)

20

707-44-15911

RING

21

707-71-61130

PLUNGER

22

07000-15100

O-RING (KIT)

23

07001-05100

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-71-70290

PLUNGER

26

07020-00000

FITTING,GREASE

27

707-71-32850

COLLAR

28

707-35-91660

RING,BACK-UP (KIT)

29

07000-15140

O-RING (KIT)

30

04260-00635

BALL

31

707-71-91270

CAP

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

707-87-14070

PLUG

35

07002-12034

O-RING (KIT)

36

707-86-66381

TUBE

37

20D-62-17860

ELBOW

38

07372-21060

BOLT

39

01643-51032

WASHER

40

07372-21045

BOLT

41

01643-51032

WASHER

42

07000-13030

O-RING (KIT)

43

01010-81080

BOLT

44

01643-31032

WASHER

45

07000-13035

O-RING (KIT)

46

707-88-22670

BRACKET

47

707-88-21351

BAND

48

07372-21035

BOLT

49

01643-51032

WASHER

50

707-88-36130

PLATE

51

07283-22738

CLIP

52

01599-01011

NUT

53

01643-31032

WASHER

54

707-88-33030

CAP,(FOR SHIPPING)

55

07371-30640

FLANGE,SPLIT (FOR SHIPPING)

56

707-88-33040

CAP,(FOR SHIPPING)

57

07371-31049

FLANGE,SPLIT (FOR SHIPPING)

58

07372-21035

BOLT,(FOR SHIPPING)

59

01643-51032

WASHER,(FOR SHIPPING)

|$64

707-99-59620

SERVICE KIT
