Запчасти Komatsu PC270-7 РУКОЯТЬ (.M) (УСИЛ.) ( ЧАС. СИСТЕМА СМАЗКИ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$8

206-70-00681

ARM ASS'Y

|$9

206-70-00451

ARM ASS'Y

|$10

206-70-00450

ARM ASS'Y

|$11

206-70-00681

ARM ASS'Y

|$13

206-70-00450

ARM ASS'Y

1

ARM

1

ARM

1

ARM

1

ARM

2

20Y-70-31272

BUSHING

2

20Y-70-31271

BUSHING

2

20Y-70-31272

BUSHING

2

20Y-70-31271

BUSHING

3

20Y-70-32410

BUSHING

3

20Y-70-32321

BUSHING

3

20Y-70-32410

BUSHING

3

20Y-70-32321

BUSHING

4

20Y-70-32331

BUSHING

4

20Y-70-32331

BUSHING

5

21K-70-12161

BUSHING

5

20Y-70-32351

BUSHING

5

21K-70-12161

BUSHING

5

20Y-70-32351

BUSHING

6

07020-00000

FITTING

7

07145-00090

SEAL

8

20Y-70-23230

SEAL

9

206-70-71341

PIN

9

206-70-71340

PIN

9

206-70-71341

PIN

9

206-70-71340

PIN

10

205-70-66581

PLATE

10

205-70-66580

PLATE

10

205-70-66581

PLATE

10

205-70-66580

PLATE

11

01010-81230

BOLT

12

01643-31232

WASHER

13

20Y-70-31431

SPACER, 1.0MM

13

20Y-70-31430

SPACER, 1.0MM

13

20Y-70-31431

SPACER, 1.0MM

13

20Y-70-31430

SPACER, 1.0MM

14

206-70-71351

PIN

14

206-70-71350

PIN

14

206-70-71351

PIN

14

206-70-71350

PIN

15

205-70-66581

PLATE

15

205-70-66580

PLATE

15

205-70-66581

PLATE

15

205-70-66580

PLATE

16

01010-81230

BOLT

17

01643-31232

WASHER

18

20Y-70-31431

SPACER, 1.0MM

18

20Y-70-31430

SPACER, 1.0MM

18

20Y-70-31431

SPACER, 1.0MM

18

20Y-70-31430

SPACER, 1.0MM

19

206-70-71451

SPACER, 2.0MM

19

206-70-71450

SPACER, 2.0MM

19

206-70-71451

SPACER, 2.0MM

19

206-70-71450

SPACER, 2.0MM

20

707-01-XS540

CYLINDER GROUP

20

707-01-XZ950

CYLINDER GROUP

20

707-01-XS540

CYLINDER GROUP

20

707-01-XZ950

CYLINDER GROUP
