/ / / / / / ЛЕВ. КЛАПАН PPCСУППОРТ (/), С ПРОПОРЦИОНАЛЬН. РЫЧАГ УПРАВЛ-Я
Запчасти Komatsu PC26MR-3 ЛЕВ. КЛАПАН PPCСУППОРТ (/), С ПРОПОРЦИОНАЛЬН. РЫЧАГ УПРАВЛ-Я СИСТЕМА УПРАВЛЕНИЯ И ОСНОВНАЯ РАМА
41
23
39
40
38
34
22
44
36
43
35
21
37
42
11
12
12
13
13
19
20
18
10
32
33
14
31
17
27
4
29
30
16
28
25
8
24
9
26
7
7
16
6
25
2
5
3
15
1
a
a
1
22M-43-21291
STOPPER
2
01010-D0820
BOLT
3
01643-10823
WASHER
4
22M-43-R1551
GUIDE
5
04205-10830
PIN
6
04050-12015
PIN, COTTER
7
21U-43-32430
BUSHING
8
22B-54-15560
STOPPER
9
01580-11008
NUT
10
22M-43-R1111
BRACKET
11
2A1-54-13190
PANEL, L.H.
12
01252-70616
BOLT
13
01643-10623
WASHER
14
22M-43-21660
GAS SPRING
15
04205-30822
PIN
16
37A-09-4Z028
PIN, COTTER
17
01643-10823
WASHER
18
22M-43-21151
PIN
19
01010-D0612
BOLT
20
01643-10623
WASHER
21
22J-54-R6131
COVER
22
2A1-06-11210
SWITCH, WORKING LIGHT
22
2A1-06-11211
SWITCH, WORKING LIGHT
23
22L-09-R3Q10
BULB 30MA 12V
23
22L-09-R3Q10
BULB 30MA 12V
23
22L-09-R3Q30
BULB 1,2W 12V
24
22M-43-R1542
LEVER, L.H.
25
06124-01616
BEARING, NEEDLE
26
22L-09-R7540
KNOB
27
37A-09-4P119
PIN, SPRING
28
22M-43-21560
SPRING
29
37A-09-4Z028
PIN, COTTER
30
01643-10823
WASHER
31
22M-43-21170
SWITCH, ASSY.
32
37A-09-1W059
SCREW
33
01643-10623
WASHER
34
2A1-06-11711
CAP, SWITCH
35
22F-06-32710
SWITCH
36
22F-06-32641
SWITCH
37
2A1-06-11711
CAP, SWITCH
38
2A1-98-11290
PLATE
\38
2A1-43-11100
LEVER, ASSEMBLY
39
22F-43-31850
LEVER
40
2A1-43-11110
LEVER
41
22F-43-31890
PIN
42
20Y-43-22250
COLLAR
43
22F-43-31880
BOOT
44
37A-09-2P410
NUT
