Запчасти Komatsu PC26MR-3 ЛЕВ. КЛАПАН PPCСУППОРТ (/) СИСТЕМА УПРАВЛЕНИЯ И ОСНОВНАЯ РАМА

1

22M-43-21291

STOPPER

2

01010-D0820

BOLT

3

01643-10823

WASHER

4

22M-43-R1551

GUIDE

5

04205-10830

PIN

6

04050-12015

PIN, COTTER

7

21U-43-32430

BUSHING

8

22B-54-15560

STOPPER

9

01580-11008

NUT

10

22M-43-R1111

BRACKET

11

22M-54-22140

COVER

12

01252-70616

BOLT

13

01643-10623

WASHER

14

22M-43-21660

GAS SPRING

15

04205-30822

PIN

16

37A-09-4Z028

PIN, COTTER

17

01643-10823

WASHER

18

22M-43-21151

PIN

19

01010-D0612

BOLT

20

01643-10623

WASHER

21

22J-54-R6131

COVER

22

2A1-06-11210

SWITCH, WORKING LIGHT

22

2A1-06-11211

SWITCH, WORKING LIGHT

23

22L-09-R3Q10

BULB 30MA 12V

23

22L-09-R3Q10

BULB 30MA 12V

23

22L-09-R3Q30

BULB 1,2W 12V

24

22M-43-R1542

LEVER, L.H.

25

06124-01616

BEARING, NEEDLE

26

22L-09-R7540

KNOB

27

37A-09-4P119

PIN, SPRING

28

22M-43-21560

SPRING

29

37A-09-4Z028

PIN, COTTER

30

01643-10823

WASHER

31

22M-43-21170

SWITCH, ASSY.

32

37A-09-1W059

SCREW

33

01643-10623

WASHER

34

2A1-06-11710

CAP, SWITCH

34

2A1-06-11711

CAP, SWITCH
