Запчасти Komatsu PC26MR-3 ГЕНЕРАТОР ДВИГАТЕЛЬ

Схема запчастей Komatsu PC26MR-3 - ГЕНЕРАТОР ДВИГАТЕЛЬ
33
1
30
35
36
34
2
31
32
4
7
6
5
11
10
8
9
12
24
29
15
16
3
27
28
21
19
20
22
14
23
25
A
17
18
26
13

Артикул

Название

Примечание

Количество

\0

22K-01-21101

TURBO ENGINE, ASSEMBLY

1

YM119717-77340

ADJUSTER, BELT

2

YM129423-77200

GENERATOR

3

YMX9490561001

NUT

4

YM119620-77380

ROTOR, ASSEMBLY

5

YM119620-79240

BEARING, BALL

6

YM119620-79250

COVER

7

YM119620-79360

WASHER, THRUST

8

YM119620-77421

COVER, ASSEMBLY

9

YM119620-79200

BEARING, BALL

10

YM119620-79210

PLATE

11

YM119620-79220

SCREW

12

YM119620-79230

STUD

13

YM119620-77440

COVER, ASSEMBLY

14

YM129423-77450

COVER

15

YM119620-77461

PULLEY

16

YM119620-77471

NUT

17

YM129423-77710

REGULATOR, ASSEMBLY

18

YM119620-79260

HOLDER

19

YM119620-79270

HOLDER, BRUSH

20

YM119620-77480

BRUSH, ASSEMBLY

21

YM119620-79280

SPRING

22

YM119620-79290

SCREW

23

YM119620-79300

SCREW

24

YM119620-79310

BOLT

25

YM119620-79320

SCREW AND WASHER

26

YM119620-79330

BOLT

27

YM119620-79340

BUSHING

28

YM119620-79350

NUT

29

YM119620-77490

COLLAR

30

YM119740-77250

BOLT

31

YM26306-100002

NUT

32

YM26106-080202

BOLT, FLANGED

33

YM119940-77270

SPACER

34

YM119802-77340

BOLT, ADJUSTING

35

YM22117-050000

WASHER

36

YM26716-050002

NUT

Выбрано товаров: 37
