Запчасти Komatsu PC250LC-6LE FIG NO. P-A МОТОР ХОДА МОТОР И ТОРМОЗ. - заводской номер A89 И UP НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

708-8H-00280

MOTOR ASSEMBLY

|$1

708-8H-04680

CASE SUB-ASSEMBLY

1

708-8H-31160

CASE

2

NSS

PLUG

3

708-8H-31210

O-RING

4

04020-01228

PIN

5

708-8H-32111

SHAFT

6

708-8H-32150

BEARING

7

708-8H-32140

BEARING

8

708-8H-05030

SPACER KIT

|$10

708-8H-32220

SPACER - 1.6 MM

|$11

708-8H-32230

SPACER - 1.7 MM

|$12

708-8H-32240

SPACER - 1.8 MM

|$13

708-8H-32250

SPACER - 1.9 MM

|$14

708-8H-32260

SPACER - 2.0 MM

|$15

708-8H-32270

SPACER - 2.1 MM

|$16

708-8H-32280

SPACER - 2.2 MM

9

708-1F-12280

SEAL

10

708-8H-32160

SPACER

11

04065-07825

RING

12

708-8H-33112

BLOCK, CYLINDER

13

708-8H-33220

PLATE, VALVE

14

708-8H-33360

PIN

15

708-8H-33141

SPACER

16

708-8H-33151

SPRING

17

04065-06020

RING

18

708-8H-33340

RETAINER, SHOE

19

708-8H-33512

RETAINER

20

708-8H-33610

PISTON SUB-ASSEMBLY

21

708-8H-33460

CAM, ROCKER

22

04260-02857

BALL

23

708-8H-34143

PISTON

24

708-8H-34151

SPRING

25

708-8K-14210

PLUG

26

07002-13334

O-RING

27

708-8H-35141

PISTON, BRAKE

28

07000-15175

O-RING

29

07001-05175

RING, BACK-UP

30

07000-15195

O-RING

31

07001-05195

RING, BACK-UP

32

708-8H-35150

SPRING

33

708-8H-35130

PLATE

34

708-8H-35120

DISC
