Запчасти Komatsu PC250LC-6LE FIG NO. K-A PPC ЛИНИЯ ХОДА MACHINES С ДОПОЛН. ГИДРОЛИНИЯ - ONE АКТУАТОР заводской номер A879 И UP КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-62-27112

HOSE ASSEMBLY

1

08034-20536

BAND, BLACK

2

20Y-62-27121

HOSE

3

20Y-62-22790

BAND, RED

4

20Y-62-27131

HOSE

5

20Y-62-22850

BAND, GREEN

6

20Y-62-27141

HOSE

7

20Y-62-22820

BAND, BLUE

8

20Y-62-22170

CLAMP

9

20Y-62-22872

HOSE

10

20Y-62-22790

BAND, RED

11

20Y-62-22881

HOSE

12

20Y-62-22820

BAND, BLUE

13

20Y-62-23282

HOSE

14

20Y-62-22830

BAND, WHITE

|$15

20Y-62-27741

HOSE ASSEMBLY

15

203-62-52350

HOSE

16

20Y-62-22790

BAND, RED

17

203-62-52340

HOSE

18

20Y-62-22820

BAND, BLUE

19

08034-00519

BAND, WHITE

24

702-16-53240

PLUG

25

07000-02018

O-RING

26

07235-10210

ELBOW

27

07002-01423

O-RING

28

08034-00519

BAND, WHITE

29

20Y-62-16170

BOLT

30

07000-02015

O-RING

31

04434-51312

CLIP

32

01010-81220

BOLT

33

01643-31032

WASHER

34

20Y-62-22180

CLAMP

35

01010-81016

BOLT

36

01643-31032

WASHER

37

207-62-62270

CLAMP

38

20Y-62-15831

BLOCK

39

207-62-33920

ELBOW

40

07002-01423

O-RING

41

07235-10210

ELBOW

42

07002-01423

O-RING

43

07230-20210

NIPPLE

44

07002-01423

O-RING

45

208-62-17550

TEE

46

07002-01423

O-RING

47

01010-81045

BOLT

48

01643-31032

WASHER
