Запчасти Komatsu PC250LC-6LE FIG NO. K- ЛЕВ. СТОЙКА РЫЧАГ И COVER КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-43-22781

LEVER ASSEMBLY, L.H

|$1

20Y-43-22233

KNOB, L.H

1

01370-10308

SCREW

2

20Y-43-22381

KNOB, L.H

|$4

20Y-43-00010

SWITCH ASSEMBLY

3

20Y-43-22421

INSERT

4

20Y-43-22441

SWITCH, L.H

5

20Y-43-22250

PLATE

6

20Y-43-22261

BOOT

7

20Y-43-22810

LEVER, L.H

8

20Y-43-22830

BOOT

9

600-411-1280

NUT

10

20Y-43-22121

CASE

11

20Y-43-16590

SCREW

|$14

20Y-43-22850

COVER ASSEMBLY

12

20Y-43-22840

COVER, L.H

13

20Y-06-21751

ASHTRAY

14

20Y-06-21350

HARNESS, WIRING

15

424-06-12850

CLIP

16

01010-80820

BOLT

17

01643-30823

WASHER

18

08034-00519

BAND, WHITE

19

08034-00310

BAND

|$23

20Y-43-21651

COVER ASSEMBLY

20

20Y-43-22111

CASE

21

20Y-43-22131

FRAME

22

20Y-43-22310

CLIP

23

20Y-43-22470

BOLT

24

20Y-43-22480

SPRING

25

198-911-5530

NUT

N/I

20Y-43-28290

SHEET

N/I

20Y-43-28310

SHEET

26

01010-81030

BOLT

27

01643-31032

WASHER

28

01252-41025

BOLT

29

01643-51032

WASHER
