Запчасти Komatsu PC250LC-6LE FIG NO. A-AA ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC250LC-6LE - FIG NO. A-AA ШАТУН И ПОРШЕНЬ ДВИГАТЕЛЬ
7
6
3
8
5
1
6
4
2

Артикул

Название

Примечание

Количество

|$0

6732-31-3101

ENGINE ROD ASSEMBLY

1

NSS

ROD, ENGINE CONNECTING

2

6732-31-3310

BOLT, CONNECTING ROD CAP - MJ11-1.25 X 59

3

6732-31-3132

BUSHING

4

6732-31-3411

BEARING, CONNECTING ROD - STD

|$5

6735-31-2140

KIT, ENGINE PISTON

5

NSS

PISTON, ENGINE

6

6732-31-2420

RING, RETAINING

7

6735-31-2030

SET, PISTON RING

8

6731-31-2410

PIN, PISTON

4

6736-39-3400

BEARING, CONNECTING ROD - 0.01 IN. (0.25 MM) O/S

4

6736-38-3400

BEARING, CONNECTING ROD - 0.02 IN. (0.50 MM) O/S

4

6736-37-3400

BEARING, CONNECTING ROD - 0.03 IN. (0.75 MM) O/S

4

6736-36-3400

BEARING, CONNECTING ROD - 0.04 IN. (1.00 MM) O/S

|$16

6735-39-2210

KIT, ENGINE PISTON - 0.02 IN. (0.50 MM) O/S

5

NSS

PISTON, ENGINE

6

6732-31-2420

RING, RETAINING

7

6732-39-2300

SET, PISTON RING

|$20

6735-38-2210

KIT, ENGINE PISTON - 0.04 IN. (1.00 MM) O/S

5

NSS

PISTON, ENGINE

6

6732-31-2420

RING, RETAINING

7

6732-38-2300

SET, PISTON RING

Выбрано товаров: 22
