Запчасти Komatsu PC250LC-6LE FIG NO. K7-A ОБОГРЕВАТЕЛЬ. - EAGLE ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-977-A050

HEATER ASSEMBLY

1

20Y-977-A470

WELDMENT, HOUSING

2

20Y-977-A640

COIL, HEATER

3

20Y-977-A820

BLOWER ASSEMBLY

4

20Y-977-A540

COVER, RECIRCULATING FILTER

5

20Y-977-A310

COVER, HOUSING

6

20Y-977-A410

FOAM, TOP COVER

7

20Y-977-A420

FOAM, RECIRCULATING FILTER

8

20Y-977-A380

SHIELD, HEAT

9

20Y-977-A610

RIVET, PLASTIC

10

20Y-977-A590

SCREW, CAP

11

120 217

WASHER, LOCK

12

425-963-A850

BOLT - 10-32 X 1/2 IN

13

425-963-A860

BOLT - 1/4-20 X 1/2 IN

14

20Y-977-A630

KNOB

15

20Y-977-A580

BOLT - 5/16-18 X 3/4 IN

16

20Y-977-A740

RESISTOR

17

20Y-977-A440

FOAM

18

20Y-977-A370

BRACKET, FILTER - AIR INTAKE

19

20Y-977-A550

DOOR, AIR INTAKE

20

425-963-A820

TIE, NYLON

21

20Y-977-A730

DUCT, AIR

22

20Y-977-A780

HARNESS, WIRING

23

20Y-977-A490

BRACKET, EVAPORATOR

24

20Y-977-A510

BRACKET, HOUSING

25

20Y-977-A520

BRACKET, SIDE MOUNTING

26

20Y-977-A560

BRACKET, TOP MOUNTING

27

20Y-977-A620

BOLT - 5/16-18 X 3/8 IN

28

20Y-977-A120

CLAMP, HOSE

29

20Y-977-A390

COVER

30

299 410 C1

CLIP, HOSE

|$31

20Y-977-A060

VALVE ASSEMBLY, WATER

31

20Y-977-A650

VALVE, WATER

32

LA 1049

HOSE, HEATER - 3 1/4 IN

33

20Y-977-A120

CLAMP, HOSE

34

20Y-977-A720

TUBE

35

20Y-977-A880

BRACKET, WATER VALVE
