Запчасти Komatsu PC250LC-6LE FIG NO. K7-7A КОНДИЦ. ВОЗДУХА - NIPPONDENSO СЕРДЦЕВИНА БЛОК ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC250LC-6LE - FIG NO. K7-7A КОНДИЦ. ВОЗДУХА - NIPPONDENSO СЕРДЦЕВИНА БЛОК ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
22
38
40
39
34
36
12
42
22
35
3
4
7
13
11
44
33
2
29
32
5
26
17
41
6
18
28
9
41
27
41
16
31
32
41
41
16
14
41
30
19
25
15
43
27
10
22
8
20
29
28
21
1
37
23
24

Артикул

Название

Примечание

Количество

|$0

ND445800-9054

CORE UNIT ASSEMBLY

1

ND245420-4093

CASE

2

ND447600-0651

EVAPORATOR

|$3

ND949142-0030

O-RING

3

ND077500-2730

THERMISTOR

4

ND246690-2840

CLAMP

5

ND447500-1031

VALVE

6

ND446870-1990

TUBE

|$8

ND949142-0030

O-RING

|$9

ND949142-0010

O-RING

7

ND949046-2150

BOLT

8

ND146984-5680

GROMMET

9

ND116730-0490

DOOR ASSEMBLY

10

ND116730-0500

DOOR ASSEMBLY

11

ND245420-4020

CASE ASSEMBLY

12

ND116452-6060

CASE

13

ND949001-1730

SCREW

14

ND116420-2781

CORE ASSEMBLY

15

ND116427-5920

PIPE

16

195-979-4841

HOSE

17

ND113600-9301

VALVE ASSEMBLY

18

ND017265-5480

HOSE

19

ND116427-5930

PIPE

20

ND246780-4220

CLAMP

21

ND246780-4000

CLAMP

22

ND949001-2690

SCREW

23

ND017732-3041

LEVER

24

ND91370-03081

SCREW

25

ND017732-3060

LEVER

26

ND017732-4600

LEVER

27

17M-911-3330

BUSHING

28

17M-911-3290

CLAMP

29

ND116662-3780

SHAFT

30

ND063700-6390

SERVO MOTOR ASSEMBLY

31

195-Z11-6280

BUSHING

32

ND90930-05201

SCREW

33

ND146668-4880

PACKING

34

ND056700-8170

RELAY ASSEMBLY

35

20Y-979-2680

RELAY

|$39

ND056700-6630

RELAY

36

ND017660-3490

BRACKET

37

ND146525-3990

BRACKET

38

ND90930-05121

SCREW

39

ND146525-4000

BRACKET

40

ND90930-06141

SCREW

41

ND949351-0720

CLAMP

42

ND246690-5150

CLAMP

43

ND443440-0030

SWITCH

|$48

ND949142-0160

O-RING

|$49

ND949142-0040

O-RING

44

ND146668-2030

PACKING

Выбрано товаров: 51
