Запчасти Komatsu PC250LC-6LC FIG NO. K-A КАБИНА ОКНАS И КРЫША ВЕНТИЛЯТОРILATION КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-54-35121

GLASS, L.H. REAR

2

20Y-54-35351

WEATHER STRIP

3

20Y-54-35132

GLASS, R.H. FRONT

4

20Y-54-35362

WEATHER STRIP

5

20Y-54-35142

GLASS, REAR

6

20Y-54-35372

WEATHER STRIP

7

20T-54-75250

TAG

|$7

20Y-54-35201

SASH ASSEMBLY

8

NSS

SASH

9

NSS

GLASS, R.H. REAR

10

NSS

SEAL

11

NSS

LOCK

12

NSS

HOOK

13

NSS

SEAL

14

NSS

GLASS

15

NSS

SASH

16

NSS

SEAL

17

NSS

SCREW

18

NSS

LINER

19

NSS

STOPPER

20

20Y-54-35550

GUARD

21

01435-30616

BOLT

22

20Y-54-35670

ROOF

23

01584-00806

NUT

24

20Y-54-36321

COVER

25

20Y-54-18690

RIVET

26

20Y-54-14590

HANDLE

27

01023-10616

SCREW

28

20Y-54-36331

SEAL

29

20Y-54-36351

LOCK ASSEMBLY

30

20Y-54-36360

COVER

31

01435-30610

BOLT

32

20Y-54-36342

SPRING ASSEMBLY, GAS

33

04052-10833

PIN

34

20Y-54-36370

STRIKER

35

01240-00816

SCREW

36

20Y-00-22880

DECAL
