Запчасти Komatsu PC250LC-6LC БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC250LC-6LC - БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ
5
5
7
11
15
9
13
5
6
16
7
12
17
7
2
10
8
14
18
1
19
3
4

Артикул

Название

Примечание

Количество

|$0

1295 494 H91

BLOCK ASSY, CYLINDER

1

NSS

BLOCK, CYLINDER

2

1240 177 H1

BUSHING

3

1240 248 H1

BOLT

4

1240 155 H1

CAP, MAIN BEARING

5

1240 154 H3

PLUG, EXPANSION

6

1246 113 H1

PLUG, EXPANSION

7

1240 152 H1

PLUG, EXPANSION

8

1240 121 H1

DOWEL, RING

|$9

1295 414 H92

KIT, BLOCK HARDWARE

9

1240 195 H1

DOWEL, RING

10

1294 769 H1

NOZZLE, PISTON

11

1240 146 H1

PLUG, WELCH

12

6732-21-6120

PIN DOWEL

13

6732-11-1910

PLUG, PIPE

14

6732-11-1930

PLUG, PIPE

N/I

6732-21-1930

O-RING

16

1240 121 H1

DOWEL, RING

17

6732-21-5530

PLUG, EXPANSION

18

1240 566 H1

PLUG, EXPANSION

2

1294 353 H1

BUSHING, OS - NO. 1 BORE

2

1294 354 H1

BUSHING, OS - NO. 2-5 BORE

4

1240 155 H1

CAP, MAIN BEARING

19

1240 669 H1

SLEEVE, CYLINDER BLOCK SERVICE

Выбрано товаров: 24
