Запчасти Komatsu PC250LC-6L FIG NO. P- МОТОР ХОДА (END КРЫШКАASSEMBLY) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$1

708-8K-04133

COVER ASSEMBLY, TRAVEL MOTOR END

1

NSS

COVER, END

2

NSS

PLUG

3

NSS

SPOOL

4

NSS

SPOOL

5

706-8E-14110

PLUG

6

07002-11023

O-RING

7

04260-00793

BALL

8

706-8E-14170

SPRING

9

706-8E-14390

PLUG

10

07002-11823

O-RING

11

20B-27-11210

BLEEDER, TRAVEL MOTOR

12

708-8K-16181

VALVE

13

708-8E-16160

PLUG

14

07002-11023

O-RING

15

706-77-72280

PLUG

16

07002-12034

O-RING

17

708-8K-16350

RING

18

708-8K-16360

SPRING

19

708-8K-16260

PLUG

20

07002-14234

O-RING

21

708-8K-16271

PISTON

22

708-8K-16280

PLUG

23

07002-11623

O-RING

24

708-8K-16150

VALVE

25

708-8K-16160

SPRING

26

708-8K-16170

PLUG

27

07002-13634

O-RING

28

07000-05270

O-RING

29

07000-12012

O-RING

30

708-8K-15190

PIN, DOWEL

31

708-18-13230

PIN

32

708-8K-11210

BOLT

33

708-8K-11220

BOLT
