Запчасти Komatsu PC250LC-6L FIG NO. P- МОТОР ХОДА (МОТОР И ТОРМОЗ.) НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

708-8J-00050

MOTOR ASSEMBLY, TRAVEL

|$1

708-8J-04112

CASE ASSEMBLY, SUB

1

NSS

CASE, MOTOR

2

NSS

PLUG

3

708-8J-12112

SHAFT

4

708-8K-12120

BEARING

5

708-8K-12161

RING

6

04064-07525

RING

7

708-8K-12141

SEAL

8

708-8K-12180

CASE

9

07000-02105

O-RING

10

04065-01124

RING

|$12

708-8J-04060

CRADLE ASSEMBLY

11

708-8K-13514

CRADLE

12

708-8J-13420

CAM, ROCKER

13

04020-01638

PIN, DOWEL

14

01252-61695

BOLT

15

708-8H-13920

SEAL

16

708-8K-13351

GUIDE, RETAINER

17

708-8K-13361

PIN

18

708-8J-13140

SEAT

19

708-8K-13150

SPRING

20

708-8J-13130

SEAT

21

04065-08025

RING, SNAP

22

708-8K-12130

BEARING

|$25

708-8J-04041

CYLINDER ASSEMBLY, BLOCK

23

708-8J-13111

CYLINDER, BLOCK

24

708-8J-13121

PLATE, VALVE

25

708-8K-13341

RETAINER, SHOE

26

708-8J-13312

PISTON ASSEMBLY, SUB

27

708-8K-15181

PISTON, BRAKE

28

708-8K-15160

O-RING

29

708-8K-15170

RING

30

07000-15230

O-RING

31

07001-05230

RING, BACK-UP

32

708-8K-15151

SPRING

33

708-8K-15111

SPACER

34

708-8K-15131

PLATE

35

708-8K-15121

DISK

36

708-8K-14161

PISTON

37

708-8K-14141

PISTON

38

708-8K-14151

SPRING

39

708-8K-14210

PLUG

40

07002-13334

O-RING
