Запчасти Komatsu PC250LC-6L FIG NO. P- КОНЕЧНАЯ ПЕРЕДАЧА НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$0

207-27-00080

FINAL DRIVE ASSEMBLY

|$2

423-33-00020

FLOATING SEAL ASSEMBLY

1

170-27-00113

SEAL RING ASSEMBLY

2

195-27-00150

O-RING ASSEMBLY

3

207-27-52160

HUB

4

207-27-51220

BEARING

5

207-27-51291

COVER

6

01010-51030

BOLT

7

01643-31032

WASHER

8

207-27-52350

O-RING

9

207-27-00110

SPACER KIT

10

207-27-51270

RETAINER

11

207-27-52310

BOLT

12

207-27-52180

CARRIER

13

207-27-52140

GEAR

14

207-27-52220

BEARING

15

207-27-52240

PIN

16

207-27-51241

HOLDER

17

01011-51805

BOLT

18

207-27-52270

SPACER

19

207-27-52131

GEAR

20

207-27-52281

GEAR

21

207-27-52190

CARRIER

22

207-27-52120

GEAR

23

207-27-52320

BEARING

24

207-27-52250

PIN

25

207-27-52260

HOLDER

26

01010-51060

BOLT

27

207-27-52110

SHAFT

28

20Y-27-11250

SPACER

29

04260-01905

BALL

30

207-27-52210

COVER

31

207-27-52341

BOLT

32

01643-31845

WASHER

33

07049-01215

PLUG

34

07044-12412

PLUG

35

07002-02434

O-RING

36

207-27-33222

SPROCKET

37

207-27-51310

BOLT, MOUNT SPROCKET

38

01010-52085

BOLT, MOUNT FINAL DRIVE ASSEMBLY

39

01643-32060

WASHER

40

207-30-51241

GUARD, TRAVEL MOTOR - L.H

|$43

207-30-51251

GUARD, TRAVEL MOTOR - R.H

41

01010-51255

BOLT, MOUNT GUARD

42

01010-51240

BOLT, MOUNT GUARD

43

01643-31232

WASHER

44

07049-01215

PLUG
