Запчасти Komatsu PC250LC-6L FIG NO. K- ЛИНИЯ РАБОЧЕГО ОБОРУД. PPC ( АКТУАТОРS) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-62-23410

HOSE

2

20Y-62-23570

HOSE

3

20Y-62-22810

BAND, YELLOW

4

20Y-62-22170

CLAMP

5

20Y-62-22180

CLAMP

6

01010-51016

BOLT

7

01643-31032

WASHER

8

08034-00536

BAND

9

203-62-58470

CLIP

10

01010-51225

BOLT

11

01643-31032

WASHER

12

20Y-62-22880

HOSE

13

20Y-62-23370

HOSE

14

20Y-62-25550

HOSE

15

20Y-62-25560

HOSE

16

20Y-62-22860

BAND, BROWN

17

20Y-62-22790

BAND, RED

18

20Y-62-22840

BAND, BLACK

19

20Y-62-22820

BAND, BLUE

20

20Y-62-22170

CLAMP

21

20Y-62-22180

CLAMP

22

01010-51016

BOLT

23

01643-31032

WASHER

24

08034-00536

BAND

25

20Y-62-22220

BLOCK

26

01011-51011

BOLT

27

01643-31032

WASHER

28

08053-01512

CLIP

29

20Y-62-16630

NIPPLE

30

07002-01423

O-RING

31

20Y-62-22271

ELBOW

32

07002-01423

O-RING

33

14X-43-14840

ELBOW

34

07002-01423

O-RING

35

20Y-06-21710

SWITCH

36

20Y-06-22430

HARNESS, WIRING
