Запчасти Komatsu PC250LC-6L FIG NO. K7- КОНДИЦ. ВОЗДУХА (БЛОК) ДЛЯ MACHINES БЕЗ SAE ЗАЩИТА ВЕНТИЛЯТОРА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

20Y-979-2112

UNIT ASSEMBLY, AIR CONDITIONER

2

20Y-979-2930

MOTOR

3

20Y-979-2940

MOTOR

4

20Y-979-2950

MOTOR

5

20Y-979-2960

MOTOR

6

20Y-979-2970

VALVE

7

20Y-979-2980

RESISTOR

8

20Y-979-2990

SWITCH

9

20Y-979-2680

RELAY

10

14X-911-7741

FILTER

11

14X-911-7750

FILTER

12

20Y-979-2181

HOSE

13

01010-51030

BOLT

14

01643-31032

WASHER

15

07281-00419

CLAMP

16

20Y-979-2122

CONDENSOR ASSEMBLY

17

20Y-979-3120

RECEIVER

18

20Y-979-2354

TUBE

|$18

20Y-979-3150

O-RING

19

20Y-979-3240

TUBE

|$20

20Y-979-3150

O-RING

20

01010-51025

BOLT

21

01643-31032

WASHER

22

07283-26155

CLIP

23

01599-01011

NUT

24

01643-31032

WASHER

26

20Y-03-21591

BRACKET

27

01010-51070

BOLT

28

01643-31032

WASHER

29

20Y-979-2453

BRACKET

30

01010-51030

BOLT

31

203-54-56970

WASHER

32

01017-51400

BOLT

33

01580-11411

NUT

34

01010-50885

BOLT

35

01643-30823

WASHER

36

20Y-03-21551

COVER

37

01010-51025

BOLT

38

01643-31032

WASHER

39

01010-50895

BOLT

40

01643-30823

WASHER

41

6204-81-6740

SPACER
