Запчасти Komatsu PC250LC-6 МЕХАНИЗМ ПОВОРОТА В СБОРЕ (ПОСТАВЛЯЕТСЯ ОТДЕЛЬНО) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|$0

206-26-00101

SWING MACHINERY A.

|$1

206-26-00100

SWING MACHINERY A.

1

20Y-26-22210

CASE

2

20Y-26-22330

BEARING

3

20Y-26-22340

BEARING

4

20Y-26-22191

COVER

5

01010-81045

BOLT

6

01643-31032

WASHER

7

20Y-26-22420

SEAL

8

206-26-67210

SHAFT

9

20Y-26-22170

CARRIER

10

20Y-26-22141

GEAR, 36 TEETH

11

20G-26-11240

BEARING

12

20Y-27-21240

WASHER

13

20Y-26-22250

PIN

14

20Y-27-21280

PIN

15

20Y-26-21240

PLATE

16

112-32-11211

BOLT

17

20Y-26-22151

GEAR, 101 TEETH

17

20Y-26-22150

GEAR, 101 TEETH

18

20Y-26-22131

GEAR, 27 TEETH

19

04064-07525

RING

20

20Y-26-22220

THRUST WASHER

21

20Y-26-22160

CARRIER

22

20Y-26-22120

GEAR, 39 TEETH

23

20Y-26-21281

BEARING

23

20Y-26-21280

BEARING

24

20Y-27-21240

WASHER

25

20Y-26-22240

PIN

26

20Y-27-21280

PIN

27

20Y-26-22110

GEAR, 22 TEETH

28

20Y-26-22230

THRUST WASHER

29

20Y-26-22410

COVER

30

01011-81450

BOLT

31

01643-31445

WASHER

32

07042-30617

PLUG

33

07042-30108

PLUG

34

07042-30415

PLUG
