Запчасти Komatsu PC240NLC-8K ОСНОВН. НАСОС (/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-00790

PUMP ASSEMBLY

|1

708-2L-00600

PUMP ASSEMBLY

|1

708-2L-01600

PUMP SUB ASSEMBLY

1

708-2L-32160

SHAFT, FRONT

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|3

WASHER, 3.1MM

|3

WASHER, 3.0MM

|3

WASHER, 2.9MM

|3

WASHER, 2.8MM

4

708-25-12790

RING, SNAP

5

708-25-52861

SEAL, OIL

6

708-2L-22160

SPACER

7

04065-06825

RING

|8

708-2L-06470

BLOCK ASSEMBLY, FRONT

8

BLOCK, CYLINDER

9

PLATE, VALVE

10

720-68-19610

PIN

11

04065-04818

RING, SNAP

12

708-2L-23131

SEAT

13

708-2L-33160

SPRING

14

708-7L-13140

SEAT

15

708-2L-23351

GUIDE, RETAINER

16

708-2L-23360

PIN

17

708-2L-33350

RETAINER, SHOE

18

708-2L-33430

PISTON SUB ASSEMBLY

|19

708-2L-06630

CRADLE ASSEMBLY

19

CRADLE

20

CAM, ROCKER

21

04020-01228

PIN, DOWEL

22

01252-61230

BOLT
