Запчасти Komatsu PC240NLC-8K РУКОЯТЬ (.M) (№K-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

206-944-K424

ARM ASSEMBLY

1

206-944-K431

ARM

2

20Y-970-3570

BRACKET (WELDED)

3

20J-70-12180

SEAT (WELDED)

4

206-62-K2740

BRACKET (WELDED)

5

20Y-62-K5830

BRACKET (WELDED)

6

20Y-62-K7290

SEAT (WELDED)

7

20Y-70-31272

BUSHING

8

20Y-70-32410

BUSHING

9

21K-70-12161

BUSHING

12

07145-00090

SEAL

13

20Y-70-23230

SEAL

14

206-70-71590

PIN

15

20Y-62-K7651

PLATE

|15

20Y-62-K7650

PLATE

16

01010-81240

BOLT

|16

01010-81230

BOLT

17

01643-31232

WASHER

18

21K-70-71650

SPACER, 1.0MM

|18

20Y-70-31431

SPACER, 1.0MM

19

206-70-51170

PIN

20

20Y-62-K7651

PLATE

|20

20Y-62-K7650

PLATE

21

01010-81240

BOLT

|21

01010-81230

BOLT

22

01643-31232

WASHER

23

21K-70-71650

SPACER, 1.0MM

|23

20Y-70-31431

SPACER, 1.0MM

24

21K-70-71660

SPACER, 2.0MM

|24

206-70-71451

SPACER, 2.0MM

25

707-01-XS870

CYLINDER GROUP

|25

707-01-XH910

CYLINDER GROUP
