Запчасти Komatsu PC240NLC-8K РУКОЯТЬ (.M) (№K-K9) T РАБОЧЕЕ ОБОРУДОВАНИЕ

1

206-944-K423

ARM

|1

206-944-K422

ARM

2

20J-70-12180

SEAT, WELDED

3

20Y-62-K5830

BRACKET, WELDED

4

206-62-K2740

BRACKET, WELDED

5

20Y-970-3570

BRACKET, WELDED

6

20Y-70-31272

BUSHING

7

20Y-70-32410

BUSHING

8

21K-70-12161

BUSHING

9

07020-00000

FITTING, GREASE

10

07145-00090

SEAL

11

20Y-70-23230

SEAL

12

206-70-71590

PIN

13

205-70-66580

PLATE

14

01010-81230

BOLT

15

01643-31232

WASHER

16

20Y-70-31431

SPACER, 1.0MM

|16

20Y-70-31430

SPACER, 1.0MM

17

206-70-51170

PIN

18

205-70-66580

PLATE

19

01010-81230

BOLT

20

01643-31232

WASHER

21

20Y-70-31431

SPACER, 1.0MM

|21

20Y-70-31430

SPACER, 1.0MM

22

206-70-71451

SPACER, 2.0MM

|22

206-70-71450

SPACER, 2.0MM

23

707-01-XS870

CYLINDER GROUP
