Запчасти Komatsu PC240NLC-8K НАВЕСНОЕ ОБОРУД-Е (ОСНОВН. ЛИНИЯ ПРАВ.) (ДЛЯ АКТУАТОР) H ГИДРАВЛИКА

1

01010-81040

BOLT

2

01643-31032

WASHER

3

20Y-62-K6941

BRACKET

|3

20Y-62-K6940

BRACKET

|3

20Y-62-51771

BRACKET

4

07049-01215

PLUG

5

07371-31049

FLANGE

6

07372-21035

BOLT

7

01643-51032

WASHER

8

07371-51260

FLANGE

9

01010-81245

BOLT

10

01643-31232

WASHER

11

20Y-62-43460

NIPPLE

12

02896-11008

O-RING

13

07002-12034

O-RING

14

11Y-62-12160

ELBOW

15

02896-11008

O-RING

16

07002-11423

O-RING

|17

20Y-970-6450

ACCUMULATOR

17

SHELL

|17

NFEB3401 A1

BLADDER ASSEMBLY

18

NFEB3026 A1

BLADDER

19

NFEB4475 Z0

CORE

20

NUT

21

CAP

22

NFEB0427 Z0

BODY ASSEMBLY

23

NFEB4477 Z0

RING

24

O-RING

25

BACK-UP RING

26

RING

27

PLATE

28

205-970-5560

O-RING

29

BUSHING

30

20Y-62-43290

ELBOW

31

07002-12434

O-RING

32

20Y-62-43280

BRACKET

33

01010-81295

BOLT

34

01643-31232

WASHER

35

175-61-51750

PLATE

36

01010-81225

BOLT

37

01643-31232

WASHER

38

01010-81285

BOLT

39

01643-31232

WASHER

40

07097-01005

HOSE

41

07000-13032

O-RING

42

07371-31049

FLANGE

43

07372-21035

BOLT

44

01643-51032

WASHER

45

07097-21218

HOSE

46

07000-13038

O-RING

47

07371-51260

FLANGE

48

01010-81245

BOLT

49

01643-31232

WASHER

50

206-00-K2990

PLATE
