Запчасти Komatsu PC240NLC-7K ЦИЛИНДР РУКОЯТИ(С КЛАПАН ПЕРЕГРУЗКИ) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XX331

ARM CYLINDER GROUP,(WITH BURST VALVE)

G-1

707-01-XX330

ARM CYLINDER GROUP,(WITH BURST VALVE)

|1

707-01-0A371

CYLINDER GROUP

|1

707-01-0A370

CYLINDER GROUP

1

707-13-14550

CYLINDER

2

707-76-80470

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

707-58-10681

ROD,PISTON

|4

707-58-10680

ROD,PISTON

5

707-76-80470

BUSHING

6

07145-00080

SEAL (KIT)

7

707-27-14930

HEAD,CYLINDER

8

07179-13114

RING,SNAP

9

176-63-56170

SEAL,DUST (KIT)

10

707-52-90780

BUSHING

11

707-51-10030

PACKING,ROD (KIT)

12

07000-15130

O-RING (KIT)

13

707-35-91420

RING,BACK-UP (KIT)

14

707-51-10640

RING,BUFFER (KIT)

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-14650

PISTON

18

707-44-14180

RING,PISTON (KIT)

19

707-39-14110

RING,WEAR (KIT)

20

707-44-14910

RING

21

707-71-61080

PLUNGER

22

07000-15090

O-RING (KIT)

23

07001-05090

RING,BACK-UP (KIT)

24

01310-01216

SCREW

25

707-71-70270

PLUNGER

26

07020-00000

FITTING,GREASE

27

707-71-32780

COLLAR

28

707-35-91420

RING,BACK-UP (KIT)

29

07000-15130

O-RING (KIT)

30

04260-00635

BALL

31

707-71-91270

CAP

32

707-83-13010

VALVE

33

07750-01628

SPRING

34

707-87-14070

PLUG

35

07002-12034

O-RING (KIT)

36

707-88-33030

HEAD

37

07371-30640

FLANGE

38

707-88-33040

CAP

39

07371-31049

FLANGE

40

07372-21035

BOLT

41

01643-51032

WASHER

K

707-99-58070

SERVICE KIT
