Запчасти Komatsu PC240NLC-6K ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№K-K999) ГИДРАВЛИКА

Схема запчастей Komatsu PC240NLC-6K - ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№K-K999) ГИДРАВЛИКА
37
40
39
38
36
29
35
34
33
34
31
32
30
32
25
23
25
24
27
26
27
28
22
15
21
20
19
20
17
18
16
18
11
9
11
10
13
12
13
14
8
1
7
6
5
6
3
4
2
4

Артикул

Название

Примечание

Количество

|1

723-48-10701

CONTROL VALVE

|1

723-48-10700

CONTROL VALVE

|1

723-46-40100

VALVE ASS'Y

1

SLEEVE

2

PISTON SUB ASS'Y

3

SPRING

4

SEAL

5

700-93-11320

O-RING

6

723-46-41950

RING

7

07002-13634

O-RING

|8

723-46-40300

VALVE ASS'Y

8

SLEEVE

9

PISTON

10

SPRING

11

SEAL

12

700-93-11320

O-RING

13

723-46-41950

RING

14

07002-13634

O-RING

|15

723-46-41100

VALVE ASS'Y

15

SLEEVE

16

PISTON SUB ASS'Y

17

SPRING

18

SEAL

19

700-93-11320

O-RING

20

723-46-41950

RING

21

07002-13634

O-RING

|22

723-46-45100

VALVE ASS'Y

22

SLEEVE

23

PISTON SUB ASS'Y

24

SPRING

25

SEAL

26

700-93-11320

O-RING

27

723-46-41950

RING

28

07002-13634

O-RING

|29

723-46-46101

VALVE ASS'Y

29

SLEEVE

30

PISTON SUB ASS'Y

31

SPRING

32

SEAL

33

700-93-11320

O-RING

34

723-46-41950

RING

35

07002-13634

O-RING

|36

723-46-15100

PLUG ASS'Y

36

PLUG

37

SCREW

38

07002-11423

O-RING

39

07000-11007

O-RING

40

07001-01007

RING,BACK-UP

Выбрано товаров: 48
