Запчасти Komatsu PC240NLC-6K ЦИЛИНДР СТРЕЛЫ(№K-K) РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

206-63-K1241

CYLINDER ASS'Y,(L.H.)

|1

206-63-K1240

CYLINDER ASS'Y,(L.H.)

|1

206-63-K1251

CYLINDER ASS'Y,(R.H.)

|1

206-63-K1250

CYLINDER ASS'Y,(R.H.)

1

206-63-K1210

CYLINDER

2

707-76-80220

BUSHING,(ROD SIDE)

|2

206-63-K1190

BUSHING,(CYLINDER SIDE)

|2

707-76-80220

BUSHING

3

07145-00080

SEAL,DUST (KIT)

4

206-63-54321

ROD,PISTON

5

206-63-K1230

HEAD,CYLINDER

6

07179-13109

RING,SNAP

7

707-56-95510

SEAL,DUST (KIT)

8

707-52-90710

BUSHING

9

707-51-95030

PACKING,ROD (KIT)

10

07000-15130

O-RING (KIT)

11

07001-05130

RING,BACK-UP (KIT)

12

707-51-95630

RING,BUFFER (KIT)

13

01010-81875

BOLT

14

707-41-11840

WASHER

15

707-36-13500

PISTON

16

707-44-13280

RING,PISTON (KIT)

17

707-39-13510

RING,WEAR (KIT)

18

707-44-13920

RING

19

707-71-61001

PLUNGER

20

07165-16870

NUT

21

707-71-32750

COLLAR

22

07001-05130

RING,BACK-UP

23

07000-15130

O-RING (KIT)

24

206-63-K1530

TUBE,L.H.

|24

206-63-K1540

TUBE,R.H.

25

07372-21060

BOLT

26

07372-21045

BOLT

27

01643-51032

WASHER

28

07000-13030

O-RING (KIT)

29

206-63-54392

BRACKET,L.H.

|29

206-63-54492

BRACKET,R.H.

30

707-88-87330

BAND

31

01010-51035

BOLT

32

01643-51032

WASHER

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER
