Запчасти Komatsu PC240NLC-6K КАБИНА (ОСНОВ.)(№K-K999) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

207-06-61510

BASE

|1

20Y-06-23312

BASE

2

20Y-06-24120

SWITCH ASS'Y,PUMP REDUNDANCY

3

569-06-61960

RELAY

4

01435-00610

BOLT

5

20Y-06-K2291

WIRING HARNESS

|5

20Y-06-K2290

WIRING HARNESS

6

283-06-16110

BOX,FUSE

7

283-06-16120

COVER,FUSE BOX

8

20Y-06-24130

SWITCH

9

283-06-16190

FUSE¤ 10A

10

205-06-73180

FUSE¤ 15A

11

22W-06-13160

FUSE¤ 20A

12

201-06-61240

FUSE¤ 30A

13

08020-00000

DIODE

14

20Y-06-24270

CLIP

15

20Y-06-21460

CLIP

16

20Y-06-23960

CLIP

17

01023-10625

SCREW

18

20Y-979-2130

BOX ASS'Y

19

01435-01016

BOLT

20

20Y-979-2221

DUCT

21

01435-00610

BOLT

22

20Y-979-2231

DUCT

23

01435-00610

BOLT

24

20Y-979-2242

DUCT

25

01435-00610

BOLT

26

7827-10-1520

RESISTOR¤ 15OHM

27

01435-00820

BOLT

28

203-06-56230

BUZZER ASS'Y

29

01435-00610

BOLT

30

7834-24-4000

CONTROLLER

|30

7834-32-3000

CONTROLLER

31

01435-00630

BOLT

32

7834-10-3000

CONTROLLER,PUMP

33

01435-00630

BOLT

34

20E-06-K1330

BRACKET

35

20Y-00-21280

PLATE
