Запчасти Komatsu PC240NLC-10 ЦИЛИНДР РУКОЯТИ, С ANTI-DROP КЛАПАН, ЦИЛИНДР РУКОЯТИ ЦИЛИНДР РУКОЯТИ, С ANTI-DROP КЛАПАН

|$1

707-E1-00180

Cylinder Assembly

1

721-13-14010

Cylinder

2

721-58-10070

Rod, Piston

3

707-76-80431

Bushing

4

07145-00080

Seal, Dust

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust

7

07020-00000

Fitting, Grease

8

707-71-35150

Collar

9

707-71-71020

Plunger

10

07000-B5130

O-Ring, (Kit : K04)

11

707-35-31310

Ring, Back-Up, (Kit : K04)

12

707-71-80320

Plunger

13

04260-00635

Ball, Steel

14

707-71-91270

Cap

15

707-27-14690

Head, Cylinder

16

707-56-10740

Seal, Dust, (Kit : K04)

17

07179-13114

Ring, Snap

18

707-52-90781

Bushing

19

707-51-10860

Packing, Rod, (Kit : K04)

20

707-51-10650

Ring, Buffer, (Kit : K04)

21

707-35-31310

Ring, Back-Up, (Kit : K04)

22

07000-B5130

O-Ring, (Kit : K04)

23

01010-81875

Bolt

24

707-41-11840

Washer

25

707-75-10160

Ring, Snap

26

707-36-14650

Piston

27

707-44-14150

Ring, Piston, (Kit : K04)

28

707-39-14110

Ring, Wear, (Kit : K04)

29

707-35-30900

Ring, Back-Up, (Kit : K04)

30

07000-B5090

O-Ring, (Kit : K04)

31

707-44-14910

Ring, Back-Up

32

01310-01216

Screw

33

707-83-13010

Valve

34

07750-01628

Spring

35

707-87-14070

Plug

36

07002-12034

O-Ring, (Kit : K04)

37

07372-21035

Bolt

38

01643-51032

Washer

39

707-88-33030

Cap

40

07371-30640

Flange, Split

41

707-88-33040

Cap

42

07371-31049

Flange, Split

K04

707-99-59430

Seal Kit, Hydraulic Cylinder
