Запчасти Komatsu PC240NLC-10 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, ВНУТР. ЧАСТИ, МОТОР ХОДА (/) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

20Y-27-00532

Final Drive Assembly

|$1

708-8F-00290

Travel Motor Assembly

1

708-8F-32130

Shaft

2

708-8F-12250

Bearing

3

708-7L-12140

Bearing

4

708-7L-05010

Spacer Kit

5

706-7G-11291

Seal, Oil

6

708-8F-12230

Spacer, T=3.2mm

7

04065-07225

Ring, Snap

11

708-8F-33360

Pin

12

708-7L-13140

Seat

13

708-8F-33160

Spring

14

04065-04818

Ring, Snap

15

708-8F-33350

Guide, Retainer

16

708-2L-33350

Retainer

17

708-8F-33310

Piston Subassembly

18

708-8F-33570

Cam, Rocker

19

708-8F-33710

Ball, Retainer

20

708-8F-34310

Piston

21

708-8F-34260

Spring

22

708-8F-34250

Spring

23

708-8F-35220

Plate

24

708-8F-35230

Plate

25

708-8F-35120

Disc

26

708-8F-35240

Piston, Brake

27

708-8F-35160

O-Ring

28

708-8F-35170

Ring, Back-Up

29

708-8F-35180

O-Ring

30

708-8F-35190

Ring, Back-Up

31

708-8F-35150

Spring

32

04025-00324

Pin, Spring
