Запчасти Komatsu PC240LC-8K ГИДРАВЛ МАСЛ. БАК H ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
|1
206-60-K8000
TANK ASSEMBLY
1
20Y-06-41114
TANK
|1
20Y-06-41113
TANK
|1
20Y-60-41112
TANK
2
203-60-31100
ELBOW ASSEMBLY
3
203-60-31160
TUBE
4
07044-12412
PLUG
5
07002-12434
O-RING
6
23B-60-42910
TEE
|6
02781-00628
UNION
7
02896-11018
O-RING
8
07002-12434
O-RING
9
02782-10522
ELBOW
10
02896-11015
O-RING
11
07002-12434
O-RING
12
20Y-62-45690
TEE
13
02896-11009
O-RING
14
02896-11008
O-RING
15
07002-12034
O-RING
16
02782-10311
ELBOW
17
02896-11009
O-RING
18
07002-11423
O-RING
19
21K-62-72491
TEE
20
02896-11018
O-RING
21
02789-00628
NUT
22
07002-12434
O-RING
23
20Y-62-15660
ADAPTER
24
07002-12034
O-RING
25
02782-10516
ELBOW
26
02896-11015
O-RING
27
07002-12034
O-RING
28
02783-10315
ELBOW
29
02896-11009
O-RING
30
07002-12034
O-RING
31
07040-12012
PLUG
32
07002-12034
O-RING
33
207-60-71182
ELEMENT
|33
207-60-71181
ELEMENT
34
20Y-60-31140
STRAINER
35
20Y-60-31131
VALVE ASSEMBLY
36
20Y-60-21240
SPRING
37
22U-60-21232
COVER
38
07000-15195
O-RING
39
01010-81230
BOLT
40
01643-31232
WASHER
|41
20Y-60-31171
STRAINER ASSEMBLY
41
207-60-61150
ROD ASSEMBLY
42
20Y-60-21320
HOLDER
43
12R-60-11230
SPRING
44
22B-60-11160
STRAINER
45
20Y-60-41162
COVER
46
07000-15160
O-RING
47
01010-81230
BOLT
48
01643-31232
WASHER
49
17A-60-11310
CAP ASSEMBLY
50
20Y-60-21470
ELEMENT
51
208-60-71180
FILLER NECK
52
20Y-60-21340
GASKET
53
01252-70516
BOLT
54
01601-20513
WASHER
55
07285-00155
CLIP
56
07270-61411
TUBE
57
205-00-73360
PLATE, OPERATING
58
01010-81635
BOLT
59
01643-31645
WASHER
60
02789-00315
NUT
61
02896-11009
O-RING
Выбрано товаров: 67
