Запчасти Komatsu PC240LC-8K ЦИЛИНДР РУКОЯТИ(КЛАПАН ПЕРЕГРУЗКИ) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-OR830

CYLINDER GROUP, (FINAL COATING)

|1

707-01-0H700

CYLINDER ASSEMBLY

1

707-13-14820

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL (K-1)

4

721-58-10070

ROD

5

707-27-14690

HEAD

6

07179-13114

RING

7

176-63-56170

SEAL (K-1)

8

707-52-90780

BUSHING

9

707-75-10160

RING

10

707-51-10030

PACKING (K-1)

11

07000-15130

O-RING (K-1)

12

707-35-91420

RING (K-1)

13

707-51-10650

RING (K-1)

14

01010-81875

BOLT

15

707-41-11840

WASHER

16

707-36-14650

PISTON

17

707-44-14150

RING (K-1)

18

707-39-14110

RING (K-1)

19

707-44-14910

RING

20

707-71-71020

PLUNGER

21

07000-15090

O-RING (K-1)

22

07001-05090

RING, BACK-UP (K-1)

23

01310-01216

SCREW

24

707-71-80270

PLUNGER

25

07020-00000

FITTING, GREASE

26

707-71-34990

COLLAR

27

707-35-91420

RING (K-1)

28

07000-15130

O-RING (K-1)

29

04260-00635

BALL

30

707-71-91270

CAP

31

707-83-13010

VALVE

32

07750-01628

SPRING

33

707-87-14070

PLUG

34

07002-12034

O-RING (K-1)

35

707-88-33040

CAP

36

07371-31049

FLANGE, SPLIT

37

07372-21035

BOLT

38

01643-51032

WASHER

39

707-88-33030

HEAD

40

07371-30640

FLANGE, SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER
