Запчасти Komatsu PC240LC-8K ЦИЛИНДР СТРЕЛЫ Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY520

BOOM CYLINDER GROUP

G-2

707-01-XY530

BOOM CYLINDER GROUP

|1

707-01-0C040

CYLINDER ASSEMBLY

1

707-13-13580

CYLINDER

2

707-76-80431

BUSHING

3

07145-00080

SEAL

4

707-58-95170

ROD

5

707-76-80431

BUSHING

6

07145-00080

SEAL

7

707-27-13961

HEAD

8

07179-13109

RING

9

707-56-95510

SEAL

10

707-52-90720

BUSHING

11

707-51-95030

PACKING

12

07000-15125

O-RING

13

707-35-91370

RING

14

707-51-95640

RING

15

01010-81875

BOLT

16

707-41-11840

WASHER

17

707-36-13771

PISTON

18

707-44-13280

RING

19

707-39-13530

RING

20

707-44-13920

RING

21

707-71-71010

PLUNGER

22

07000-15085

O-RING

23

707-35-90960

RING

24

01310-01216

SCREW

25

707-71-34820

COLLAR

26

707-35-91370

RING

27

07000-15125

O-RING

28

707-86-66420

TUBE

|28

707-86-66430

TUBE

29

01435-01055

BOLT

30

01435-01040

BOLT

31

07000-13030

O-RING

32

707-88-22750

BRACKET

|32

707-88-22760

BRACKET

33

707-88-21490

BAND

34

01435-01030

BOLT

35

07283-22738

CLIP

36

01599-01011

NUT

37

01643-31032

WASHER

38

707-88-33030

HEAD

39

07371-30640

FLANGE

40

07372-21035

BOLT

41

01643-31032

WASHER

|K

707-99-50620

SERVICE KIT
