Запчасти Komatsu PC240LC-8K ОСНОВН. НАСОС (7/) Y ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

708-2L-00790

PUMP ASSEMBLY

|1

708-2L-00600

PUMP ASSEMBLY

|1

708-2L-01600

PUMP SUB ASSEMBLY

1

708-2L-32170

SHAFT, REAR

2

708-2L-32150

BEARING

3

708-2E-05040

WASHER KIT

|3

WASHER, 3.1MM

|3

WASHER, 3.0MM

|3

WASHER, 2.9MM

|3

WASHER, 2.8MM

4

708-25-12790

RING, SNAP

|5

708-2L-06480

BLOCK ASSEMBLY, REAR

5

BLOCK, CYLINDER

6

PLATE, VALVE

7

720-68-19610

PIN

8

04065-04818

RING, SNAP

9

708-2L-23131

SEAT

10

708-2L-33160

SPRING

11

708-7L-13140

SEAT

12

708-2L-23351

GUIDE, RETAINER

13

708-2L-23360

PIN

14

708-2L-33350

RETAINER, SHOE

15

708-2L-33430

PISTON SUB ASSEMBLY

|16

708-2L-06630

CRADLE ASSEMBLY

16

CRADLE

17

CAM, ROCKER

18

04020-01228

PIN, DOWEL

19

01252-61230

BOLT
