Запчасти Komatsu PC240LC-8K РУКОЯТЬ (.M) (№K-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

206-70-K2254

ARM ASSEMBLY

1

206-970-K792

ARM

2

20Y-70-32E50

SEAT (WELDED)

3

20Y-970-3570

BRACKET (WELDED)

4

20J-70-12180

SEAT (WELDED)

5

206-62-K2740

BRACKET (WELDED)

6

20Y-62-K7290

SEAT (WELDED)

7

20Y-70-31272

BUSHING

8

20Y-70-32410

BUSHING

9

21K-70-12161

BUSHING

10

07145-00090

SEAL

11

20Y-70-23230

SEAL

12

20Y-70-31160

PIN

13

20Y-62-K7651

PLATE

|13

20Y-62-K7650

PLATE

14

01010-81240

BOLT

|14

01010-81230

BOLT

15

01643-31232

WASHER

16

21K-70-71650

SPACER, 1.0MM

|16

20Y-70-31431

SPACER, 1.0MM

17

20Y-70-11180

PIN

18

205-70-66580

PLATE

19

01010-81230

BOLT

20

01643-31232

WASHER

21

21K-70-71650

SPACER, 1.0MM

|21

20Y-70-31431

SPACER, 1.0MM

22

21K-70-71660

SPACER, 2.0MM

|22

206-70-71451

SPACER, 2.0MM

23

707-H1-X0110

CYLINDER GROUP

|23

707-F1-X0110

CYLINDER GROUP

|23

707-01-XS880

CYLINDER GROUP

|23

707-01-XH920

CYLINDER GROUP
