Запчасти Komatsu PC240LC-8K РУКОЯТЬ (.M) (№K-) T РАБОЧЕЕ ОБОРУДОВАНИЕ

|1

206-70-K2244

ARM ASSEMBLY

1

206-970-K812

ARM

2

20Y-70-22B81

PLATE (WELDED)

3

20Y-70-22F80

BAR (WELDED)

4

20Y-70-22F90

BAR (WELDED)

5

20Y-970-3570

BRACKET (WELDED)

6

20Y-70-32E50

SEAT (WELDED)

7

20J-70-12180

SEAT (WELDED)

8

206-62-K2740

BRACKET (WELDED)

9

20Y-62-K7290

SEAT (WELDED)

10

20Y-70-31272

BUSHING

11

20Y-70-32410

BUSHING

12

21K-70-12161

BUSHING

13

07145-00090

SEAL

14

20Y-70-23230

SEAL

15

206-70-71340

PIN

16

20Y-62-K7651

PLATE

|16

20Y-62-K7650

PLATE

17

01010-81240

BOLT

|17

01010-81230

BOLT

18

01643-31232

WASHER

19

21K-70-71650

SPACER, 1.0MM

|19

20Y-70-31431

SPACER, 1.0MM

20

206-70-71350

PIN

21

205-70-66580

PLATE

22

01010-81230

BOLT

23

01643-31232

WASHER

24

21K-70-71650

SPACER, 1.0MM

|24

20Y-70-31431

SPACER, 1.0MM

25

21K-70-71660

SPACER, 2.0MM

|25

206-70-71451

SPACER, 2.0MM

26

707-H1-X0100

CYLINDER GROUP

|26

707-F1-X0100

CYLINDER GROUP

|26

707-01-XS870

CYLINDER GROUP

|26

707-01-XH910

CYLINDER GROUP
