Запчасти Komatsu PC240LC-8K DIESEL ЧАСТЬICULATE ФИЛЬТР. И КРЕПЛЕНИЕ(№K-) B КОМПОНЕНТЫ ДВИГАТЕЛЯ

1

20Y-01-K2231

MUFFLER ASSEMBLY

2

20Y-01-K2160

BRACKET

3

20Y-01-K2250

RING

4

20Y-01-K2121

PRESSURE SENSOR

5

20Y-01-K2111

SENSOR

6

20Y-01-K2060

MOUNT

7

20Y-01-K1950

FLANGE

8

20Y-01-K1961

TUBE

|8

20Y-01-K1960

TUBE

9

20Y-01-K1970

CLAMP

10

20Y-01-K2071

PLATE

|10

20Y-01-K2070

PLATE

11

01224-40620

SCREW

12

01643-30623

WASHER

13

01580-10605

NUT

14

01435-01030

BOLT

15

20Y-01-K2081

BRACKET

|15

20Y-01-K2080

BRACKET

16

01435-01030

BOLT

17

01435-01035

BOLT

18

01643-31032

WASHER

19

01580-11008

NUT

20

20Y-01-K2091

BOLT

|20

20Y-01-K2090

BOLT

21

01435-01030

BOLT

22

01435-01035

BOLT

23

01643-31032

WASHER

24

01580-11008

NUT

25

6754-11-5420

BRACKET

26

01435-01025

BOLT

27

01435-01035

BOLT

28

01643-31032

WASHER

29

01580-01008

NUT

30

20Y-01-K2190

TUBE

31

07260-20950

HOSE

32

07285-00155

CLAMP

33

20Y-01-K2291

BRACKET

34

207-01-K1650

WATER SEPERATOR

35

01023-70410

SCREW

36

207-01-K1090

FITTING

37

207-01-K1080

FITTING

38

01010-81225

BOLT

39

01643-31232

WASHER

40

20Y-01-K2260

FILTER BAG
