Запчасти Komatsu PC240LC-8 СТАРТЕР, .KW, ВНУТР. ЧАСТИ СТАРТЕР, .KW

|1

600-863-4210

Starting Motor Assembly 24

|1

600-863-5111

Starting Motor Assembly

1

ND028100-5410

Yoke Assembly

2

ND028200-5250

Armature Assembly

|3

ND949100-3161

Bearing, Ball

3

ND949100-5290

Bearing, Ball

|4

ND949100-3540

Bearing, Ball

4

ND028300-6551

Clutch Assembly

5

ND028099-3270

Starting Motor Kit

6

ND028300-6751

Clutch Assembly

7

ND949100-4500

Bearing, Ball

8

ND949100-1920

Bearing, Ball

9

ND949170-4040

Spring

10

ND028381-0071

Shaft

11

ND128401-5621

Housing

12

ND153400-6740

Switch Assembly, Magnetic

13

ND128099-5770

Starting Motor Kit

14

ND028099-5100

Starting Motor Kit

15

ND053660-0443

Plunger

16

ND053404-0240

Gasket

17

ND053505-0290

Cover

18

ND053480-7560

Bolt Assembly, Terminal

19

ND949047-4440

Bolt

20

ND028065-0250

Bushing, Drain

21

ND028510-0880

Holder Assembly, Brush

22

ND028520-0011

Spring, Brush

23

ND028501-7711

Frame

24

ND128961-0010

Ball

25

ND949170-4070

Spring

26

ND028371-3210

Pinion, Starter

27

ND028306-0070

Roller, Clutch

28

ND028063-0030

Retainer

29

ND028062-0130

Cover

30

ND949042-3680

Bolt

31

ND90801-10050

O-ring

32

ND949042-3690

Bolt

33

ND949006-4720

Screw

34

ND949056-4480

Nut

35

ND028327-0171

Retainer, Snap

36

ND90258-10001

Washer

37

ND028901-0361

Seal

38

ND028371-3200

Pinion

39

ND949007-6530

Screw

40

ND028530-1090

Brush Assembly

41

ND028530-1100

Brush Assembly

42

ND949007-6850

Screw

43

ND028062-5790

Cover

44

ND90170-10061

Nut

45

ND028901-5190

Seal

46

ND90200-06241

Washer
