Запчасти Komatsu PC240LC-6K ЦИЛИНДР СТРЕЛЫ(№K-) РАБОЧЕЕ ОБОРУДОВАНИЕ

G1

206-63-X3500

BOOM CYLINDER GROUP,(L.H.)

|G1

206-63-X3510

BOOM CYLINDER GROUP,(R.H.)

|1

206-63-03601

CYLINDER ASS'Y

1

206-63-52740

CYLINDER

2

206-63-52720

ROD,PISTON

3

707-27-13560

HEAD,CYLINDER

4

707-36-13731

PISTON

5

707-71-61040

PLUNGER

6

01310-01216

SCREW

7

01010-81875

BOLT

8

707-41-11840

WASHER

9

707-56-95510

SEAL,DUST

10

07179-13109

RING,SNAP

11

707-51-95030

PACKING,ROD

12

707-51-95630

RING,BUFFER

13

07000-15125

O-RING

14

707-35-91370

RING,BACK-UP

15

707-52-90720

BUSHING

16

707-44-13280

RING,PISTON

17

707-39-13510

RING,WEAR

18

707-44-13920

RING

19

707-76-80410

BUSHING,(CYLINDER SIDE)

20

07145-00080

SEAL,DUST

21

707-76-80220

BUSHING,(ROD SIDE)

22

707-71-32860

COLLAR

23

707-35-90960

RING,BACK-UP

24

07000-15085

O-RING

25

206-63-52770

TUBE,L.H.

|25

206-63-52870

TUBE,R.H.

26

01435-01040

BOLT

27

01435-01055

BOLT

28

07000-13030

O-RING

29

206-63-54392

BRACKET,L.H.

|29

206-63-54492

BRACKET,R.H.

30

707-88-87330

BAND

31

01010-81035

BOLT

32

01643-51032

WASHER

33

07283-22738

CLIP

34

01599-01011

NUT

35

01643-31032

WASHER
