Запчасти Komatsu PC240LC-6K ЛЕВ. ДВЕРЬ (ДВЕРЬ) (КАБИНА)(№K-K999) ЧАСТИ КОРПУСА

1

20Y-54-K7533

COVER

2

20Y-54-K7550

SEAL

3

20Y-54-K7992

SHEET

|3

20Y-54-K7991

SHEET

4

01010-51235

BOLT

5

01643-31232

WASHER

6

20Y-54-33290

PLATE

7

20Y-54-K7413

COVER

8

20Y-54-K7741

SHEET

9

205-54-53550

DOVE TAIL

10

01010-50612

BOLT

11

01643-30623

WASHER

12

01010-51235

BOLT

|12

01010-51235

BOLT

13

01643-31232

WASHER

14

20Y-54-33290

PLATE

15

20Y-54-KA281

FRAME

|15

20Y-54-KA130

FRAME

16

20Y-54-KA140

FRAME

17

01010-51230

BOLT

18

01643-31232

WASHER

19

20Y-54-33170

BRACKET

20

01010-51225

BOLT

21

01643-31232

WASHER

22

205-54-51970

DOVE TAIL

23

01010-50616

BOLT

24

01643-30623

WASHER

25

20Y-54-K7421

PLATE

26

01010-51225

BOLT

27

01643-31232

WASHER

28

20Y-54-K2230

SUPPORT

29

01641-21016

WASHER

30

04050-13018

PIN,COTTER

31

20Y-54-K7541

SHEET

32

20Y-54-KA150

SHEET

33

20Y-54-K7560

SEAL

34

20Y-54-K7441

SEAL

35

20Y-54-K7430

SEAL

36

20Y-54-11611

STOPPER

|36

203-54-56710

STOPPER

37

01580-11008

NUT

38

20Y-54-K8932

FRAME

|38

20Y-54-K8931

FRAME

39

20Y-54-KA240

FRAME

40

01010-51230

BOLT

41

01643-31232

WASHER

42

01010-51230

BOLT

43

01643-31232

WASHER

44

01010-51240

BOLT

45

20Y-54-K9281

BRACKET

|45

20Y-54-K9280

BRACKET
