Запчасти Komatsu PC240LC-10 РУКОЯТЬ, MM, РУКОЯТЬ РУКОЯТЬ, MM

|$1

206-944-K425

Arm Assembly

1

206-944-K432

Arm

2

20Y-970-3570

Bracket (Welded)

3

20Y-70-K6410

Seat (Welded)

4

206-62-K2740

Bracket (Welded)

5

20Y-62-K5830

Bracket (Welded)

6

20Y-62-K7290

Seat (Welded)

7

20Y-70-31272

Bushing

8

20Y-70-32410

Bushing

9

21K-70-12161

Bushing

10

07020-00000

Fitting, Grease

11

07145-00090

Seal, Dust

12

20Y-70-23230

Seal, Dust

13

206-70-22250

Pin

14

205-70-66581

Plate

15

01010-81230

Bolt

16

01643-31232

Washer

17

21K-70-71650

Spacer, T=1.0mm

18

206-70-22260

Pin

19

205-70-66581

Plate

20

01010-81230

Bolt

21

01643-31232

Washer

22

21K-70-71650

Spacer, T=1.0mm

23

21K-70-71660

Spacer, T=2.0mm

24

20Y-62-K7651

Plate

25

01010-81240

Bolt

26

707-H1-X0230

Cylinder Assembly
