Запчасти Komatsu PC240LC-10 ЦИЛИНДР СТРЕЛЫ, С ANTI-DROP КЛАПАН, ЦИЛИНДР СТРЕЛЫ, LHS (/) ЦИЛИНДР СТРЕЛЫ, С ANTI-DROP КЛАПАН

|$1

707-E1-00200

Cylinder Assembly

1

721-13-13160

Cylinder

2

707-58-95280

Rod, Piston

3

707-76-80431

Bushing

4

07145-00080

Seal, Dust, (Kit : K07)

5

707-76-80431

Bushing

6

07145-00080

Seal, Dust, (Kit : K07)

7

707-71-35180

Collar

8

707-35-31260

Ring, Back-Up, (Kit : K07)

9

07000-B5125

O-Ring, (Kit : K07)

10

707-71-71010

Plunger

11

707-27-13850

Head, Cylinder

12

707-56-95740

Seal, Dust, (Kit : K07)

13

07179-13109

Ring, Snap

14

707-52-90721

Bushing

15

707-51-95030

Packing, Rod, (Kit : K07)

16

707-51-95650

Ring, Buffer, (Kit : K07)

17

707-35-31260

Ring, Back-Up, (Kit : K07)

18

07000-B5125

O-Ring, (Kit : K07)

19

01010-81875

Bolt

20

707-41-11840

Washer

21

707-75-95030

Ring, Snap

22

707-36-13771

Piston

23

707-44-13250

Ring, Piston, (Kit : K07)

24

707-39-13530

Ring, Wear, (Kit : K07)

25

707-44-13920

Ring, Back-Up

26

01310-01216

Screw

27

07000-B5085

O-Ring, (Kit : K07)

28

707-35-30850

Ring, Back-Up, (Kit : K07)

K07

707-99-50400

Seal Kit, Hydraulic Cylinder
